SIR-56ST3FF
EMITTER IR 950NM 100MA T 1 3/4Manufacturer: Rohm Semiconductor
Categories: LED Emitters - Infrared, UV, Visible
Quality Control: Learn More
Rohm Semiconductor SIR-56ST3FF is a T 1 3/4 through-hole mounted infrared emitter operating at a 950nm wavelength. This component offers a typical forward voltage of 1.3V and a maximum DC forward current of 100mA. At a forward current of 50mA, it achieves a radiant intensity of 5.6mW/sr, with a 30° viewing angle. The emitter is designed for operation within an ambient temperature range of -25°C to 85°C. It finds application in various industrial sectors, including automation, sensing, and security systems. This component is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | T 1 3/4 |
| Wavelength | 950nm |
| Mounting Type | Through Hole |
| Type | Infrared (IR) |
| Orientation | Top View |
| Operating Temperature | -25°C ~ 85°C (TA) |
| Voltage - Forward (Vf) (Typ) | 1.3V |
| Viewing Angle | 30° |
| Current - DC Forward (If) (Max) | 100mA |
| Radiant Intensity (Ie) Min @ If | 5.6mW/sr @ 50mA |
