BD1601MUV-E2
IC LED DRIVER RGLTR 30MA 16VQFNManufacturer: Rohm Semiconductor
Categories: LED Drivers
Quality Control: Learn More
The Rohm Semiconductor BD1601MUV-E2 is a 4-output DC-DC regulator featuring a switched capacitor topology. This LED driver IC is designed for surface mounting and comes in a 16-VFQFN exposed pad package (VQFN016V3030), supplied on tape and reel. It supports an output current of 30mA per channel and operates with an internal switch at a frequency of 1MHz. The device accepts supply voltages ranging from 2.7V to a maximum of 5.5V. Its compact design and efficient regulation make it suitable for applications in consumer electronics and portable devices where precise LED current control is critical. Operating temperature range is from -30°C to 85°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 14 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-VFQFN Exposed Pad |
| Voltage - Output | - |
| Mounting Type | Surface Mount |
| Number of Outputs | 4 |
| Frequency | 1MHz |
| Type | DC DC Regulator |
| Operating Temperature | -30°C ~ 85°C (TA) |
| Applications | - |
| Current - Output / Channel | 30mA |
| Internal Switch(s) | Yes |
| Topology | Switched Capacitor (Charge Pump) |
| Supplier Device Package | VQFN016V3030 |
| Dimming | - |
| Voltage - Supply (Min) | 2.7V |
| Voltage - Supply (Max) | 5.5V |
