LB-302MP
DISPLAY 7SEG 0.3"" DBL GRN 10DIPManufacturer: Rohm Semiconductor
Categories: LED Character and Numeric
Quality Control: Learn More
Rohm Semiconductor's LB-302MP is a dual-digit, 0.30-inch (7.62mm) green 7-segment display module. This 10-DIP packaged component features a common cathode configuration, requiring a typical forward voltage of 2.1V and operating at 10mA per segment to achieve a luminous intensity of 9mcd. The display exhibits a peak wavelength of 563nm. With overall dimensions of 0.591 inches (15.00mm) in height, 0.610 inches (15.50mm) in width, and 0.283 inches (7.20mm) in depth, and packaged in bulk, the LB-302MP is suitable for applications in industrial control, instrumentation, and consumer electronics requiring clear numeric or character representation. Its maximum power dissipation is rated at 60mW.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 10-DIP (0.400"", 10.16mm) |
| Color | Green |
| Display Type | 7-Segment |
| Size / Dimension | 0.591"" H x 0.610"" W x 0.283"" D (15.00mm x 15.50mm x 7.20mm) |
| Number of Characters | 2 |
| Millicandela Rating | 9mcd |
| Common Pin | Common Cathode |
| Digit/Alpha Size | 0.30"" (7.62mm) |
| Voltage - Forward (Vf) (Typ) | 2.1V |
| Current - Test | 10mA |
| Wavelength - Peak | 563nm |
| Power Dissipation (Max) | 60mW |
