BS2103F-E2
IC GATE DRVR HALF-BRIDGE 8SOPManufacturer: Rohm Semiconductor
Categories: Gate Drivers
Quality Control: Learn More
Rohm Semiconductor BS2103F-E2 is an 8-SOP half-bridge gate driver IC designed for efficient control of N-channel MOSFETs and IGBTs. This non-inverting driver features independent channels, providing flexibility in driving configurations. It supports a high-side voltage up to 600V with a bootstrap capability. The device offers peak output currents of 60mA sourcing and 130mA sinking, with typical rise and fall times of 200ns and 100ns, respectively. Operating across a supply voltage range of 10V to 18V, it maintains performance from -40°C to 150°C. This component is suitable for applications in power supply systems and motor control.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Voltage - Supply | 10V ~ 18V |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 600 V |
| Supplier Device Package | 8-SOP |
| Rise / Fall Time (Typ) | 200ns, 100ns |
| Channel Type | Independent |
| Driven Configuration | Half-Bridge |
| Number of Drivers | 2 |
| Gate Type | IGBT, N-Channel MOSFET |
| Logic Voltage - VIL, VIH | 1V, 2.6V |
| Current - Peak Output (Source, Sink) | 60mA, 130mA |
| Programmable | Not Verified |
