BD6369GUL-E2
IC HALF BRIDGE DRVR 400MA 15VCSPManufacturer: Rohm Semiconductor
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
Rohm Semiconductor's BD6369GUL-E2 is a full half-bridge driver designed for DC motor control and general-purpose applications. This component utilizes Power MOSFET technology and is housed in a compact 15-VCSP50L2 (2.1x2.1) CSP package, supplied on tape and reel. It features an output current capability of 400mA per channel and a load voltage range of 2.5V to 5.5V, with a supply voltage range also from 2.5V to 5.5V. Integrated fault protection includes over-temperature and undervoltage lockout (UVLO). The device operates across a junction temperature range of -25°C to 150°C. Its logic interface simplifies integration into various system designs.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 15-UFBGA, CSPBGA |
| Mounting Type | Surface Mount |
| Interface | Logic |
| Operating Temperature | -25°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge (2) |
| Voltage - Supply | 2.5V ~ 5.5V |
| Rds On (Typ) | 800mOhm |
| Applications | DC Motors, General Purpose |
| Current - Output / Channel | 400mA |
| Current - Peak Output | - |
| Technology | Power MOSFET |
| Voltage - Load | 2.5V ~ 5.5V |
| Supplier Device Package | 15-VCSP50L2 (2.1x2.1) |
| Fault Protection | Over Temperature, UVLO |
| Load Type | Inductive |
