QH8KE5TCR
100V 2.0A, DUAL NCH+NCH, TSMT8,Manufacturer: Rohm Semiconductor
Categories: FET, MOSFET Arrays
Quality Control: Learn More
Mosfet Array 100V 2A (Ta) 1.5W (Ta) Surface Mount TSMT8
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SMD, Flat Leads |
| Mounting Type | Surface Mount |
| Configuration | 2 N-Channel |
| Operating Temperature | 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| Power - Max | 1.5W (Ta) |
| Drain to Source Voltage (Vdss) | 100V |
| Current - Continuous Drain (Id) @ 25°C | 2A (Ta) |
| Input Capacitance (Ciss) (Max) @ Vds | 90pF @ 50V |
| Rds On (Max) @ Id, Vgs | 202mOhm @ 2A, 10V |
| Gate Charge (Qg) (Max) @ Vgs | 2.8nC @ 10V |
| FET Feature | - |
| Vgs(th) (Max) @ Id | 2.5V @ 1mA |
| Supplier Device Package | TSMT8 |
