DAP202UT106
DIODE ARRAY GP 80V 100MA UMD3Manufacturer: Rohm Semiconductor
Categories: Diode Arrays
Quality Control: Learn More
Rohm Semiconductor's DAP202UT106 is a General Purpose Diode Array featuring a common anode configuration. This component offers a maximum DC reverse voltage of 80 V and an average rectified current of 100 mA per diode. It exhibits a typical forward voltage of 1.2 V at 100 mA and a low reverse leakage current of 100 nA at 70 V. The device boasts a reverse recovery time of 4 ns, classifying it as a small signal diode suitable for speeds up to 200 mA. The DAP202UT106 is housed in a SC-70, SOT-323 (UMD3) package, designed for surface mounting. Operating junction temperatures can reach up to 150°C. This diode array finds application in various electronic systems, including consumer electronics and industrial control. It is supplied on tape and reel for automated assembly.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-70, SOT-323 |
| Mounting Type | Surface Mount |
| Speed | Small Signal =< 200mA (Io), Any Speed |
| Reverse Recovery Time (trr) | 4 ns |
| Technology | Standard |
| Diode Configuration | 1 Pair Common Anode |
| Current - Average Rectified (Io) (per Diode) | 100mA |
| Supplier Device Package | UMD3 |
| Operating Temperature - Junction | 150°C (Max) |
| Voltage - DC Reverse (Vr) (Max) | 80 V |
| Voltage - Forward (Vf) (Max) @ If | 1.2 V @ 100 mA |
| Current - Reverse Leakage @ Vr | 100 nA @ 70 V |
