BM2P012
IC OFFLINE SWITCH FLYBACK 7DIPManufacturer: Rohm Semiconductor
Categories: DC DC Switching Regulators
Quality Control: Learn More
Rohm Semiconductor's BM2P012 is a flyback switching regulator IC offering a positive, single output. This component is designed for offline power supply applications, specifically in a 7-lead, 7-DIP package. It features an output current capability of 950mA and operates at a switching frequency of 65kHz. The input voltage range is from 8.9V to 26V. The BM2P012 is suitable for through-hole mounting and is supplied in a tube. Typical applications include consumer electronics, industrial automation, and lighting control systems. The operating temperature range is -40°C to 105°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 28 week(s)Product Status: ActivePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-DIP (0.300"", 7.62mm), 7 Leads |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Current - Output | 950mA |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 65kHz |
| Voltage - Input (Max) | 26V |
| Topology | Flyback |
| Supplier Device Package | 7-DIP |
| Synchronous Rectifier | No |
| Voltage - Input (Min) | 8.9V |
