BD95500MUV-E2
IC REG BUCK ADJ 6A VQFN040-V6060Manufacturer: Rohm Semiconductor
Categories: DC DC Switching Regulators
Quality Control: Learn More
Rohm Semiconductor presents the BD95500MUV-E2, a high-performance buck switching regulator designed for demanding applications. This adjustable positive output device offers a robust 6A output current capability and operates within an input voltage range of 3V to 20V. Featuring a switching frequency adjustable from 200kHz to 600kHz, it allows for efficient power conversion in compact designs. The BD95500MUV-E2 incorporates a synchronous rectifier for improved efficiency and is housed in a VQFN040V6060 package, a 40-VFQFN exposed pad, suitable for surface mounting. Its adjustable output voltage can be set as low as 0.7V. This component is widely utilized in power management solutions for automotive, industrial, and consumer electronics sectors requiring reliable step-down voltage conversion.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 15 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 40-VFQFN Exposed Pad |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 6A |
| Operating Temperature | -10°C ~ 100°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 200kHz ~ 600kHz |
| Voltage - Input (Max) | 20V |
| Topology | Buck |
| Supplier Device Package | VQFN040V6060 |
| Synchronous Rectifier | Yes |
| Voltage - Output (Max) | 5V |
| Voltage - Input (Min) | 3V |
| Voltage - Output (Min/Fixed) | 0.7V |
