BA9744FV-E2
IC REG CTRLR BUCK/BOOST 16-SSOPBManufacturer: Rohm Semiconductor
Categories: DC DC Switching Controllers
Quality Control: Learn More
Buck, Boost Regulator Positive or Negative Output Step-Up, Step-Down DC-DC Controller IC 16-SSOP-B
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 7 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-LSSOP (0.173"", 4.40mm Width) |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Up, Step-Down |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive or Negative |
| Frequency - Switching | 10kHz ~ 800kHz |
| Topology | Buck, Boost |
| Voltage - Supply (Vcc/Vdd) | 2.5V ~ 35V |
| Supplier Device Package | 16-SSOP-B |
| Synchronous Rectifier | Yes |
| Control Features | Dead Time Control, Soft Start |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 100% |
| Clock Sync | No |
| Number of Outputs | 2 |
Request a Quote
