UMF21NTR
TRANS NPN PREBIAS/PNP 0.15W UMT6Manufacturer: Rohm Semiconductor
Categories: Bipolar Transistor Arrays, Pre-Biased
Quality Control: Learn More
The Rohm Semiconductor UMF21NTR is a pre-biased bipolar transistor array featuring one NPN and one PNP transistor within a compact UMT6 surface mount package. This device offers a collector current capability of up to 100mA for the NPN and 500mA for the PNP, with a maximum collector-emitter breakdown voltage of 50V for the NPN and 12V for the PNP. Transition frequencies are specified at 250MHz for the NPN and 260MHz for the PNP. Integrated base resistors (R1) of 10kOhms and emitter-base resistors (R2) of 10kOhms are included for simplified circuit design. This component is suitable for applications in consumer electronics and industrial control systems requiring compact, low-power switching and amplification. The UMF21NTR is supplied on tape and reel (TR).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Mounting Type | Surface Mount |
| Transistor Type | 1 NPN Pre-Biased, 1 PNP |
| Power - Max | 150mW |
| Current - Collector (Ic) (Max) | 100mA, 500mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V, 12V |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 500µA, 10mA / 250mV @ 10mA, 200mA |
| Current - Collector Cutoff (Max) | 500nA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 30 @ 5mA, 5V / 270 @ 10mA, 2V |
| Frequency - Transition | 250MHz, 260MHz |
| Resistor - Base (R1) | 10kOhms |
| Resistor - Emitter Base (R2) | 10kOhms |
| Supplier Device Package | UMT6 |
