2SC5662T2LN
RF TRANS NPN 11V 0.05A VMT3Manufacturer: Rohm Semiconductor
Categories: Bipolar RF Transistors
Quality Control: Learn More
Rohm Semiconductor NPN RF Transistor, Part Number 2SC5662T2LN. This high-frequency bipolar transistor operates with an 11V collector-emitter breakdown voltage and a maximum collector current of 50mA. Featuring a transition frequency of 3.2GHz, it offers a typical noise figure of 3.5dB at 500MHz. The device boasts a minimum DC current gain (hFE) of 56 at 5mA, 10V. Engineered for demanding applications, it is packaged in a VMT3 (SOT-723) surface-mount case and can withstand operating temperatures up to 150°C. This component is suitable for use in wireless communications and general RF amplification circuits. Supplied in Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-723 |
| Mounting Type | Surface Mount |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Gain | - |
| Power - Max | 150mW |
| Current - Collector (Ic) (Max) | 50mA |
| Voltage - Collector Emitter Breakdown (Max) | 11V |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 56 @ 5mA, 10V |
| Frequency - Transition | 3.2GHz |
| Noise Figure (dB Typ @ f) | 3.5dB @ 500MHz |
| Supplier Device Package | VMT3 |
