RT7020GS
IC GATE DRVR HALF-BRIDGE 8SOPManufacturer: Richtek USA Inc.
Categories: Gate Drivers
Quality Control: Learn More
The Richtek USA Inc. RT7020GS is a half-bridge gate driver IC. This non-inverting, two-channel driver is designed for surface mount applications, utilizing an 8-SOP package. It supports IGBT and N-Channel MOSFET gate drive with independent channel control. Key specifications include peak output currents of 300mA source and 600mA sink, with typical rise and fall times of 70ns and 35ns respectively. The device operates with a supply voltage range of 10V to 20V and features a high-side voltage capability up to 600V (bootstrap). Logic input thresholds are set at 0.8V (VIL) and 2.5V (VIH). This component is commonly employed in power supply and motor control applications. It is supplied in tape and reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Voltage - Supply | 10V ~ 20V |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 600 V |
| Supplier Device Package | 8-SOP |
| Rise / Fall Time (Typ) | 70ns, 35ns |
| Channel Type | Independent |
| Driven Configuration | Half-Bridge |
| Number of Drivers | 2 |
| Gate Type | IGBT, N-Channel MOSFET |
| Logic Voltage - VIL, VIH | 0.8V, 2.5V |
| Current - Peak Output (Source, Sink) | 300mA, 600mA |
| Programmable | Not Verified |
