RT8152BGQW
IC REG CTRLR VID 1OUT WQFN-32Manufacturer: Richtek USA Inc.
Categories: DC DC Switching Controllers
Quality Control: Learn More
The Richtek USA Inc. RT8152BGQW is a single-phase, step-down DC-DC buck controller designed for demanding power delivery applications. This device features a wide input voltage range of 4.5V to 25V and supports switching frequencies up to 1MHz, enabling efficient power conversion. The RT8152BGQW integrates essential control functions including current limit, dead time control, enable, frequency control, power good signaling, and soft start for robust operation. Its 32-WFQFN exposed pad package facilitates efficient thermal management for surface mount applications. This controller is commonly utilized in high-performance computing, networking equipment, and industrial power systems where precise voltage regulation and high efficiency are critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-WFQFN Exposed Pad |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Down |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | Up to 1MHz |
| Topology | Buck |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 25V |
| Supplier Device Package | 32-WQFN (5x5) |
| Synchronous Rectifier | No |
| Control Features | Current Limit, Dead Time Control, Enable, Frequency Control, Power Good, Soft Start |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | - |
| Clock Sync | Yes |
| Number of Outputs | 1 |
