EL4511CUZ-T7A
IC VIDEO SYNC SEPARATOR 24QSOPManufacturer: Renesas Electronics Corporation
Categories: Video Processing
Quality Control: Learn More
Renesas Electronics Corporation EL4511CUZ-T7A is a video sync separator IC designed for robust performance in consumer video applications. This component reliably separates synchronization signals from composite video inputs, supporting NTSC, PAL, and SECAM broadcast standards. The device is packaged in a compact 24-QSOP (24-QSOP) surface-mount configuration, suitable for high-density board designs. Operating with a supply voltage of up to 6V, the EL4511CUZ-T7A offers efficient synchronization signal extraction for video processing and display systems. This part is supplied on tape and reel (TR) for automated manufacturing processes.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 24-SSOP (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Function | Separator |
| Voltage - Supply | 6V |
| Applications | Consumer Video |
| Standards | NTSC, PAL, SECAM |
| Supplier Device Package | 24-QSOP |
| Control Interface | - |
