ISL59311IRZ
IC VIDEO AMP TRI DIFF 32-QFNManufacturer: Renesas Electronics Corporation
Categories: Video Amps and Modules
Quality Control: Learn More
The Renesas Electronics Corporation ISL59311IRZ is a triple,
high-speed, high-performance video amplifier designed for differential
signaling. This electronic component features a -3dB bandwidth of 650
MHz and a slew rate of 1500V/µs, enabling efficient signal
processing for demanding applications. It offers three independent
amplifying channels, each capable of delivering 60 mA of output
current per channel. The device operates from a single supply voltage
ranging from 4.5V to 5.5V, consuming a typical supply current of 7 mA.
The ISL59311IRZ is housed in a 32-QFN (5x6) package with an exposed
pad for enhanced thermal performance and is available in bulk
packaging. Its robust design makes it suitable for applications in
broadcast video, high-definition displays, and test and measurement
equipment. The surface mount mounting type facilitates integration
into compact board designs.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 32-VFQFN Exposed Pad |
| Output Type | Differential |
| Mounting Type | Surface Mount |
| Applications | Differential |
| Slew Rate | 1500V/µs |
| Voltage - Supply, Single/Dual (±) | 4.5V ~ 5.5V |
| Supplier Device Package | 32-QFN (5x6) |
| Number of Circuits | 3 |
| Current - Supply | 7 mA |
| Current - Output / Channel | 60 mA |
| -3db Bandwidth | 650 MHz |
Request a Quote
