UPC8112TB-E3-A
RF AND BASEBAND CIRCUIT, BIPOLARManufacturer: Renesas Electronics Corporation
Categories: RF Mixers
Quality Control: Learn More
Renesas Electronics Corporation UPC8112TB-E3-A is a bipolar RF and baseband circuit designed as a single-mixer down converter for cellular applications. This component operates within the 800MHz to 2GHz frequency range, providing a typical gain of 15dB and a noise figure of 9dB. The UPC8112TB series device is supplied in a 6-SuperMiniMold package, suitable for surface mount applications. With a supply voltage range of 2.7V to 3.3V and a current draw of 8.5mA, this IC is engineered for efficient performance in RF front-end designs. Its capabilities are utilized across various wireless communication systems, including mobile handsets and other portable devices.
Additional Information
Series: UPC8112TBRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Mounting Type | Surface Mount |
| Frequency | 800MHz ~ 2GHz |
| RF Type | Cellular |
| Voltage - Supply | 2.7V ~ 3.3V |
| Gain | 15dB |
| Current - Supply | 8.5mA |
| Secondary Attributes | Down Converter |
| Noise Figure | 9dB |
| Number of Mixers | 1 |
| Supplier Device Package | 6-SuperMiniMold |
