F1385NBGI
VFQFPN 6.00X6.00X0.80 MM, 0.50MMManufacturer: Renesas Electronics Corporation
Categories: RF Demodulators
Quality Control: Learn More
Renesas Electronics Corporation F1385NBGI is a high-performance RF demodulator IC designed for demanding wireless applications. This component operates within the 3.2GHz to 4.4GHz frequency range, making it suitable for advanced communication systems. Featuring a 4.05GHz ~ 2.85GHz LO frequency and a 20dB gain, the F1385NBGI provides excellent signal processing capabilities. Its low noise figure of 20dB and P1dB of 0dBm ensure signal integrity in challenging RF environments. The device is supplied in a 36-WFQFN Exposed Pad package, measuring 6.00 x 6.00 x 0.80 mm with a 0.50mm pitch, facilitating efficient surface mounting. The current supply requirement is 210 mA, with an operating voltage range of 4.75V to 5.25V. This RF demodulator finds application in sectors such as telecommunications and radar systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 36-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Function | Demodulator |
| Voltage - Supply | 4.75V ~ 5.25V |
| Gain | 20dB |
| Noise Figure | 20dB |
| P1dB | 0dBm |
| LO Frequency | 4.05GHz ~ 2.85GHz |
| RF Frequency | 3.2GHz ~ 4.4GHz |
| Supplier Device Package | 36-VFQFPN (6x6) |
| Current - Supply | 210 mA |
