X1227S8-2.7A
IC RTC CLK/CALENDAR I2C 8SOICManufacturer: Renesas Electronics Corporation
Categories: Real Time Clocks
Quality Control: Learn More
The Renesas Electronics Corporation X1227S8-2-7A is a Clock/Calendar IC featuring an I2C, 2-Wire Serial interface. This device operates within a voltage range of 2.7V to 5.5V for the main supply and 1.8V to 5.5V for battery backup. It offers essential timekeeping functions, including clock and calendar tracking with support for YY-MM-DD-dd date format and HH:MM:SS (12/24 hr) time format. Key features include alarm functionality, leap year compensation, supervisor capabilities, and a watchdog timer, contributing to robust system monitoring. Timekeeping current is typically between 10µA and 20µA at 2.7V to 5V. The component is housed in an 8-SOIC (0.154", 3.90mm Width) package, designed for surface mounting. Typical applications span industrial automation, consumer electronics, and automotive systems where precise timekeeping and system supervision are critical.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | Alarm, Leap Year, Supervisor, Watchdog Timer |
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Memory Size | - |
| Interface | I2C, 2-Wire Serial |
| Type | Clock/Calendar |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 2.7V ~ 5.5V |
| Time Format | HH:MM:SS (12/24 hr) |
| Date Format | YY-MM-DD-dd |
| Supplier Device Package | 8-SOIC |
| Voltage - Supply, Battery | 1.8V ~ 5.5V |
| Current - Timekeeping (Max) | 10µA ~ 20µA @ 2.7V ~ 5V |
| Programmable | Not Verified |
