PS9124-V-AX
OPTOISO 3.75KV OPN COLLECTOR 5SOManufacturer: Renesas Electronics Corporation
Categories: Optocouplers, Optoisolators
Quality Control: Learn More
Renesas Electronics Corporation PS9124-V-AX is a single-channel optoisolator featuring an open-collector output. It provides 3750Vrms isolation and offers a high Common Mode Transient Immunity (CMTI) of 10kV/µs. This device supports data rates up to 10Mbps with a maximum forward current of 25mA and an output current capability of 25mA per channel. The PS9124-V-AX has a typical forward voltage of 1.55V and operates within a supply voltage range of 2.7V to 3.6V or 4.5V to 5.5V. Its typical rise and fall times are 20ns and 5ns, respectively, with a maximum propagation delay of 75ns for both low-to-high and high-to-low transitions. Packaged in a 5-SO (6-SOIC) surface-mount configuration, this component is suitable for applications in industrial automation, motor control, and power supply systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Not For New DesignsPackaging: BagDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bag |
| Package / Case | 6-SOIC (0.173"", 4.40mm Width), 5 Leads |
| Output Type | Open Collector |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 100°C |
| Voltage - Supply | 2.7V ~ 3.6V, 4.5V ~ 5.5V |
| Voltage - Forward (Vf) (Typ) | 1.55V |
| Data Rate | 10Mbps |
| Input Type | DC |
| Voltage - Isolation | 3750Vrms |
| Current - DC Forward (If) (Max) | 25mA |
| Inputs - Side 1/Side 2 | 1/0 |
| Supplier Device Package | 5-SO |
| Rise / Fall Time (Typ) | 20ns, 5ns |
| Common Mode Transient Immunity (Min) | 10kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 75ns, 75ns |
| Number of Channels | 1 |
| Current - Output / Channel | 25 mA |
