PS9123-F3-AX
OPTOISO 3.75KV PUSH PULL 5SOManufacturer: Renesas Electronics Corporation
Categories: Optocouplers, Optoisolators
Quality Control: Learn More
Logic Output Optoisolator 15Mbps Push-Pull, Totem Pole 3750Vrms 1 Channel 15kV/µs CMTI 5-SO
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-SOIC (0.173"", 4.40mm Width), 5 Leads |
| Output Type | Push-Pull, Totem Pole |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 100°C |
| Voltage - Supply | 4.5V ~ 5.5V |
| Voltage - Forward (Vf) (Typ) | 1.55V |
| Data Rate | 15Mbps |
| Input Type | DC |
| Voltage - Isolation | 3750Vrms |
| Current - DC Forward (If) (Max) | 20mA |
| Inputs - Side 1/Side 2 | 1/0 |
| Supplier Device Package | 5-SO |
| Rise / Fall Time (Typ) | - |
| Common Mode Transient Immunity (Min) | 15kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 60ns, 60ns |
| Number of Channels | 1 |
| Current - Output / Channel | 13 mA |
