PS8802-2-V-AX
SO-8Manufacturer: Renesas Electronics Corporation
Categories: Optocouplers, Optoisolators
Quality Control: Learn More
Optoisolator Darlington with Base Output 2500Vrms 2 Channel 8-SSOP
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: StripDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Strip |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | Darlington with Base |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 100°C |
| Voltage - Forward (Vf) (Typ) | 1.7V |
| Input Type | DC |
| Current - Output / Channel | 8mA |
| Voltage - Isolation | 2500Vrms |
| Current Transfer Ratio (Min) | 15% @ 16mA |
| Vce Saturation (Max) | - |
| Current Transfer Ratio (Max) | 45% @ 16mA |
| Supplier Device Package | 8-SSOP |
| Voltage - Output (Max) | - |
| Turn On / Turn Off Time (Typ) | - |
| Rise / Fall Time (Typ) | - |
| Number of Channels | 2 |
| Current - DC Forward (If) (Max) | 25 mA |
