PS2806-4-A

OPTOISOLTR 2.5KV 4CH DARL 16SOIC

Manufacturer: Renesas Electronics Corporation

Categories: Optocouplers, Optoisolators

Quality Control: Learn More

Renesas Electronics Corporation NEPOC series PS2806-4-A is a 4-channel optoisolator featuring Darlington output transistors. This component provides 2500Vrms isolation and is housed in a 16-SOIC package, suitable for surface mounting. The device accepts AC and DC input signals and offers a minimum current transfer ratio of 200% at 1mA. Each channel can handle an output current of up to 100mA, with a maximum forward current rating of 50mA. The output saturation voltage (Vce) is a maximum of 1V, and the typical forward voltage (Vf) is 1.1V. Designed for reliable operation across a temperature range of -55°C to 100°C, the PS2806-4-A finds application in industrial automation, power supply control, and telecommunications equipment where signal isolation is critical.

Additional Information

Series: NEPOCRoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Not For New DesignsPackaging: StripDatasheet:
Technical Details:
PackagingStrip
Package / Case16-SOIC (0.173"", 4.40mm Width)
Output TypeDarlington
Mounting TypeSurface Mount
Operating Temperature-55°C ~ 100°C
Voltage - Forward (Vf) (Typ)1.1V
Input TypeAC, DC
Current - Output / Channel100mA
Voltage - Isolation2500Vrms
Current Transfer Ratio (Min)200% @ 1mA
Vce Saturation (Max)1V
Current Transfer Ratio (Max)-
Supplier Device Package16-SOP
Voltage - Output (Max)40V
Turn On / Turn Off Time (Typ)-
Rise / Fall Time (Typ)200µs, 200µs
Number of Channels4
Current - DC Forward (If) (Max)50 mA
