UPD78F1827AGAA2-GAM-E3-G
IC MCU 16BIT 96KB FLASH 48LFQFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
The Renesas Electronics Corporation 78K0R/Fx3 series microcontroller, part number UPD78F1827AGAA2-GAM-E3-G, features a 16-bit 78K/0R core processor operating at 20MHz. This device offers 96KB of FLASH program memory and 6KB of RAM, with an 11-channel 10-bit A/D converter. Connectivity options include CSI, I2C, and UART/USART interfaces. Peripherals such as DMA, LVD, PWM, and WDT are integrated. The microcontroller is housed in a 48-LFQFP (7x7) surface mount package and operates within a voltage range of 2.7V to 5.5V across an ambient temperature range of -40°C to 125°C. It is supplied on a Tape & Reel (TR) package. This component finds application in automotive, industrial, and consumer electronics sectors.
Additional Information
Series: 78K0R/Fx3RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 48-LQFP |
| Mounting Type | Surface Mount |
| Speed | 20MHz |
| Program Memory Size | 96KB (96K x 8) |
| RAM Size | 6K x 8 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | 78K/0R |
| Data Converters | A/D 11x10b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | CSI, I2C, UART/USART |
| Peripherals | DMA, LVD, PWM, WDT |
| Supplier Device Package | 48-LFQFP (7x7) |
| Number of I/O | 32 |
| Programmable | Not Verified |
