UPD70F3796GC-UEU-AX
IC MCU 32BIT 512KB FLASH 100LQFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation's V850ES/JG3-L series microcontroller, part number UPD70F3796GC-UEU-AX, offers a 32-bit single-core V850ES processor operating at 20MHz. This device features 512KB of FLASH program memory and 40KB of RAM. Integrated peripherals include DMA, LVD, PWM, and WDT. Connectivity options comprise CSI, EBI/EMI, I2C, UART/USART, and USB. The microcontroller includes 12x10-bit Analog-to-Digital converters and 2x8-bit Digital-to-Analog converters. It is housed in a 100-LFQFP (14x14) surface-mount package and operates from a 2V to 3.6V supply. The UPD70F3796GC-UEU-AX is suitable for applications in automotive, industrial, and consumer electronics.
Additional Information
Series: V850ES/JG3-LRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 100-LQFP |
| Mounting Type | Surface Mount |
| Speed | 20MHz |
| Program Memory Size | 512KB (512K x 8) |
| RAM Size | 40K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | V850ES |
| Data Converters | A/D 12x10b; D/A 2x8b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 2V ~ 3.6V |
| Connectivity | CSI, EBI/EMI, I2C, UART/USART, USB |
| Peripherals | DMA, LVD, PWM, WDT |
| Supplier Device Package | 100-LFQFP (14x14) |
| Number of I/O | 80 |
| Programmable | Not Verified |
