R7FA6M3AH3CFC#AA0
IC MCU 32BIT 2MB FLASH 176LFQFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation RA6M3 microcontroller, part number R7FA6M3AH3CFC-AA0, features an ARM® Cortex®-M4 32-bit core operating at 120MHz. This device offers 2MB of FLASH program memory and 640KB of RAM, complemented by 64KB of EEPROM. Connectivity options include CANbus, Ethernet, I2C, SPI, UART/USART, and USB, among others. The integrated peripherals include DMA, LVD, POR, PWM, and WDT. This surface mount component comes in a 176-LFQFP package and supports a voltage range of 2.7V to 3.6V. It is suitable for applications in industrial automation, automotive, and consumer electronics.
Additional Information
Series: RA6M3RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 176-LQFP |
| Mounting Type | Surface Mount |
| Speed | 120MHz |
| Program Memory Size | 2MB (2M x 8) |
| RAM Size | 640K x 8 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 64K x 8 |
| Core Processor | ARM® Cortex®-M4 |
| Data Converters | A/D 24x12b SAR; D/A 2x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 3.6V |
| Connectivity | CANbus, EBI/EMI, Ethernet, I2C, IrDA, MMC/SD, SCI, SPI, UART/USART, USB |
| Peripherals | DMA, LVD, POR, PWM, WDT |
| Supplier Device Package | 176-LFQFP (24x24) |
| Number of I/O | 124 |
| Programmable | Not Verified |
