R5S77631AY266BGV
IC MCU 32BIT ROMLESS 449FBGAManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation SuperH® SH7780 microcontroller, part number R5S77631AY266BGV. This 32-bit, ROMless SH-4A core microcontroller operates at 266MHz. It features a 449-FBGA (21x21) package and supports surface mount installation. Connectivity options include Audio Codec, I2C, Memory Card, SCI, SIM, SIO, SSI, and USB. Integrated peripherals include DMA, LCD controller, POR, and WDT. The device offers analog-to-digital conversion with 4x10-bit inputs and digital-to-analog conversion with 2x8-bit outputs. It includes 16K x 8 RAM and 111 I/O pins. Operating voltage is between 3V and 3.6V, with an operating temperature range of -20°C to 75°C. This component is utilized in automotive and industrial applications.
Additional Information
Series: SuperH® SH7780RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 449-FBGA |
| Mounting Type | Surface Mount |
| Speed | 266MHz |
| Program Memory Size | - |
| RAM Size | 16K x 8 |
| Operating Temperature | -20°C ~ 75°C (TA) |
| Oscillator Type | External |
| Program Memory Type | ROMless |
| EEPROM Size | - |
| Core Processor | SH-4A |
| Data Converters | A/D 4x10b; D/A 2x8b |
| Core Size | 32-Bit |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | Audio Codec, I2C, Memory Card, SCI, SIM, SIO, SSI, USB |
| Peripherals | DMA, LCD, POR, WDT |
| Supplier Device Package | 449-FBGA (21x21) |
| Number of I/O | 111 |
| Programmable | Not Verified |
