R5F72395BDFP#V0
IC MCU 32BIT 512KB FLASH 120LQFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation SuperH® SH7239 microcontroller, part number R5F72395BDFP-V0, features a 32-Bit Single-Core SH2A-FPU processor operating at 100MHz. This device offers 512KB of FLASH program memory and 64KB of RAM. Peripherals include DMA, POR, PWM, and WDT. Connectivity options are provided via CANbus, SCI, SPI, and UART/USART interfaces. The unit is equipped with 16 channels of 12-bit A/D converters and supports 85 I/O lines. Packaged in a 120-LQFP for surface mounting, it operates within a temperature range of -40°C to 85°C (TA) and requires a supply voltage of 4.5V to 5.5V. This component is suitable for applications in automotive and industrial automation.
Additional Information
Series: SuperH® SH7239RoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 120-LQFP |
| Mounting Type | Surface Mount |
| Speed | 100MHz |
| Program Memory Size | 512KB (512K x 8) |
| RAM Size | 64K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | SH2A-FPU |
| Data Converters | A/D 16x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
| Connectivity | CANbus, SCI, SPI, UART/USART |
| Peripherals | DMA, POR, PWM, WDT |
| Number of I/O | 85 |
| Programmable | Not Verified |
Request a Quote
