R5F72375ADFP#V0
IC MCU 32BIT 512KB FLASH 120LQFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation's SuperH® SH7237 microcontroller, part number R5F72375ADFP-V0, features a 32-bit SH2A single-core processor operating at 160MHz. This 120-LQFP packaged device offers 512KB of FLASH program memory and 64KB of RAM. Peripheral support includes CANbus, EBI/EMI, SCI, SPI, UART/USART, along with DMA, POR, PWM, and WDT. It also incorporates a 16-bit, 12-channel Analog-to-Digital converter. Designed for surface mounting, this component is suitable for applications within the automotive and industrial sectors. The operating temperature range is -40°C to 85°C (TA), with a supply voltage range of 3V to 3.6V.
Additional Information
Series: SuperH® SH7237RoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 120-LQFP |
| Mounting Type | Surface Mount |
| Speed | 160MHz |
| Program Memory Size | 512KB (512K x 8) |
| RAM Size | 64K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | SH2A |
| Data Converters | A/D 16x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | CANbus, EBI/EMI, SCI, SPI, UART/USART |
| Peripherals | DMA, POR, PWM, WDT |
| Number of I/O | 85 |
| Programmable | Not Verified |
