R5F72167ADFP#V1
IC MCU 32BIT 1MB FLASH 176LFQFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation SuperH® SH7216 microcontroller, part number R5F72167ADFP-V1, features a 32-bit SH2A-FPU core operating at 200MHz. This device offers 1MB of FLASH program memory and 128KB of RAM, with 112 I/O lines. Connectivity options include CANbus, Ethernet, I2C, SCI, SPI, and USB. Integrated peripherals include DMA, PWM, and WDT. It also incorporates 8x12-bit A/D converters. The component is housed in a 176-LFQFP (24x24) package, suitable for surface mounting. Operating temperature range is -40°C to 85°C. This microcontroller is utilized in industrial automation, automotive, and consumer electronics applications.
Additional Information
Series: SuperH® SH7216RoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 176-LQFP |
| Mounting Type | Surface Mount |
| Speed | 200MHz |
| Program Memory Size | 1MB (1M x 8) |
| RAM Size | 128K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | SH2A-FPU |
| Data Converters | A/D 8x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | CANbus, Ethernet, I2C, SCI, SPI, USB |
| Peripherals | DMA, PWM, WDT |
| Supplier Device Package | 176-LFQFP (24x24) |
| Number of I/O | 112 |
| Programmable | Not Verified |
