R5F5630DCDBG#U0
IC MCU 32BIT 1.5MB FLSH 176LFBGAManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
The Renesas Electronics Corporation R5F5630DCDBG-U0 is a 32-bit microcontroller from the RX600 series. This single-core RX processor operates at 100MHz and features 1.5MB of FLASH program memory and 128KB of RAM. Connectivity options include EBI/EMI, I2C, LINbus, SCI, SPI, and USB interfaces. The device is equipped with an 8x10-bit and 21x12-bit Analog-to-Digital converter, along with 2x10-bit Digital-to-Analog converters. Peripherals include DMA, LVD, POR, PWM, and WDT. This component is housed in a 176-LFBGA (13x13) package suitable for surface mounting and operates within a temperature range of -40°C to 85°C. The R5F5630DCDBG-U0 finds application in industrial automation, automotive, and consumer electronics sectors.
Additional Information
Series: RX600RoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 176-LFBGA |
| Mounting Type | Surface Mount |
| Speed | 100MHz |
| Program Memory Size | 1.5MB (1.5M x 8) |
| RAM Size | 128K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 32K x 8 |
| Core Processor | RX |
| Data Converters | A/D 8x10b, 21x12b; D/A 2x10b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 3.6V |
| Connectivity | EBI/EMI, I2C, LINbus, SCI, SPI, USB |
| Peripherals | DMA, LVD, POR, PWM, WDT |
| Supplier Device Package | 176-LFBGA (13x13) |
| Number of I/O | 148 |
| Programmable | Not Verified |
