R5F51117ADNE#UA
IC MCU 32BIT 384KB FLASH 48HWQFNManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation R5F51117ADNE-UA is a 32-bit microcontroller from the RX111 series. This single-core, 32MHz device features 384KB of FLASH program memory and 64KB of RAM. Connectivity options include I2C, SCI, SPI, and USB interfaces. The R5F51117ADNE-UA is equipped with a 10-channel 12-bit Analog-to-Digital converter and 8KB of EEPROM. Integrated peripherals include DMA, LVD, POR, PWM, and WDT. This surface-mount component is housed in a 48-HWQFN (7x7) package with an exposed pad, operating within a voltage range of 1.8V to 3.6V and an ambient temperature range of -40°C to 85°C. Its internal oscillator provides clocking. This microcontroller is suitable for applications in industrial automation, consumer electronics, and IoT devices.
Additional Information
Series: RX111RoHS Status: ROHS3 CompliantManufacturer Lead Time: 30 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 48-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Speed | 32MHz |
| Program Memory Size | 384KB (384K x 8) |
| RAM Size | 64K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 8K x 8 |
| Core Processor | RX |
| Data Converters | A/D 10x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 3.6V |
| Connectivity | I2C, SCI, SPI, USB |
| Peripherals | DMA, LVD, POR, PWM, WDT |
| Supplier Device Package | 48-HWQFN (7x7) |
| Number of I/O | 30 |
| Programmable | Not Verified |
