R5F21365CNFP#V0
IC MCU 16BIT 24KB FLASH 64LFQFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
The Renesas Electronics Corporation R8C/3x/36C series R5F21365CNFP-V0 is a 16-bit microcontroller featuring a 20MHz R8C core. This device offers 24KB of FLASH program memory and 4KB of EEPROM. It includes 2KB of RAM and supports up to 59 I/O lines. Connectivity options include I2C, LINbus, SIO, SSU, and UART/USART. The integrated data converters provide 12x10-bit A/D and 2x8-bit D/A capabilities. Peripherals include Power-On Reset (POR), Pulse Width Modulation (PWM), Voltage Detect, and Watchdog Timer (WDT). This microcontroller is designed for surface mount applications and operates within a temperature range of -20°C to 85°C. Its internal oscillator simplifies system design. The 64-LFQFP (10x10) package facilitates compact board layouts. This component is suitable for automotive, industrial automation, and consumer electronics applications.
Additional Information
Series: R8C/3x/36CRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 64-LQFP |
| Mounting Type | Surface Mount |
| Speed | 20MHz |
| Program Memory Size | 24KB (24K x 8) |
| RAM Size | 2K x 8 |
| Operating Temperature | -20°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 4K x 8 |
| Core Processor | R8C |
| Data Converters | A/D 12x10b; D/A 2x8b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 5.5V |
| Connectivity | I2C, LINbus, SIO, SSU, UART/USART |
| Peripherals | POR, PWM, Voltage Detect, WDT |
| Supplier Device Package | 64-LFQFP (10x10) |
| Number of I/O | 59 |
| Programmable | Not Verified |
