R5F211B2NP#U0
IC MCU 16BIT 8KB FLASH 28HWQFNManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation R8C/1x/1B Series microcontroller, part number R5F211B2NP-U0. This 16-bit R8C core microcontroller operates at 20MHz and features 8KB of FLASH program memory with 512 bytes of RAM. Integrated peripherals include a 4-channel 10-bit Analog-to-Digital converter, I2C, SIO, SSU, and UART/USART communication interfaces. The device also incorporates LED drivers, Power-On Reset (POR), Voltage Detect, and a Watchdog Timer (WDT). It utilizes an internal oscillator and is supplied in a 28-HWQFN (5x5) surface mount package. The operating voltage range is 2.7V to 5.5V, with an operating temperature of -20°C to 85°C. This component is suitable for applications in industrial control, consumer electronics, and automotive systems.
Additional Information
Series: R8C/1x/1BRoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Last Time BuyPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 28-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Speed | 20MHz |
| Program Memory Size | 8KB (8K x 8) |
| RAM Size | 512 x 8 |
| Operating Temperature | -20°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | R8C |
| Data Converters | A/D 4x10b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | I2C, SIO, SSU, UART/USART |
| Peripherals | LED, POR, Voltage Detect, WDT |
| Supplier Device Package | 28-HWQFN (5x5) |
| Number of I/O | 13 |
| Programmable | Not Verified |
Request a Quote
