R5F21134DFP#U0
IC MCU 16BIT 16KB FLASH 32LQFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation R8C/1x/13 Series microcontroller, part number R5F21134DFP-U0. This 16-bit microcontroller features a 20MHz R8C core with 16KB of FLASH program memory and 1KB of RAM. It includes an internal oscillator and supports SIO and UART/USART connectivity. The device is equipped with 12x10-bit A/D converters and peripherals such as LED, POR, Voltage Detect, and WDT. Offering 22 I/O lines, it operates within a voltage range of 2.7V to 5.5V and has an operating temperature range of -40°C to 85°C. Supplied in a 32-LQFP (7x7) surface mount package, this component is suitable for applications in the automotive, industrial automation, and consumer electronics sectors.
Additional Information
Series: R8C/1x/13RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 32-LQFP |
| Mounting Type | Surface Mount |
| Speed | 20MHz |
| Program Memory Size | 16KB (16K x 8) |
| RAM Size | 1K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 4K x 8 |
| Core Processor | R8C |
| Data Converters | A/D 12x10b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | SIO, UART/USART |
| Peripherals | LED, POR, Voltage Detect, WDT |
| Supplier Device Package | 32-LQFP (7x7) |
| Number of I/O | 22 |
| Programmable | Not Verified |
