R5F21122DFP#U0
IC MCU 16BIT 8KB FLASH 32LQFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation R8C/1x/12 Series microcontroller, part number R5F21122DFP-U0. This 16-bit microcontroller features an R8C core operating at 16MHz. It offers 8KB of FLASH program memory (8K x 8) and 512 bytes of RAM. On-chip peripherals include an 8-channel, 10-bit A/D converter, internal oscillator, LED drivers, and a watchdog timer (WDT). Connectivity options comprise SIO and UART/USART interfaces. The device is housed in a 32-LQFP (7x7) surface-mount package and operates from a 2.7V to 5.5V supply. Applications for this component are found in industrial automation, consumer electronics, and automotive systems. It is supplied in trays.
Additional Information
Series: R8C/1x/12RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 32-LQFP |
| Mounting Type | Surface Mount |
| Speed | 16MHz |
| Program Memory Size | 8KB (8K x 8) |
| RAM Size | 512 x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 4K x 8 |
| Core Processor | R8C |
| Data Converters | A/D 8x10b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | SIO, UART/USART |
| Peripherals | LED, WDT |
| Supplier Device Package | 32-LQFP (7x7) |
| Number of I/O | 22 |
| Programmable | Not Verified |
