R5F21114FP#W4
IC MCU 16BIT 16KB FLASH 32LQFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation R8C/1x/11 Series R5F21114FP-W4 microcontroller. This 16-bit device features a 20MHz R8C core with 16KB of FLASH program memory and 1KB of RAM. Connectivity options include SIO and UART/USART. It is equipped with 22 I/O lines and includes peripherals such as LED, POR, Voltage Detect, and WDT. The integrated 12-channel, 10-bit A/D converter is suitable for various sensing applications. Supplied in a 32-LQFP (7x7) surface mount package via Tape & Reel (TR), this component operates within a voltage range of 2.7V to 5.5V and an ambient temperature range of -20°C to 85°C. This microcontroller is commonly utilized in industrial automation, consumer electronics, and automotive applications.
Additional Information
Series: R8C/1x/11RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-LQFP |
| Mounting Type | Surface Mount |
| Speed | 20MHz |
| Program Memory Size | 16KB (16K x 8) |
| RAM Size | 1K x 8 |
| Operating Temperature | -20°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | R8C |
| Data Converters | A/D 12x10b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | SIO, UART/USART |
| Peripherals | LED, POR, Voltage Detect, WDT |
| Supplier Device Package | 32-LQFP (7x7) |
| Number of I/O | 22 |
| Programmable | Verified |
