M3062AFCTGP#U
IC MCU 16BIT 128KB FLSH 100LFQFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation M16C™ M16C/60/62PT series microcontroller, part number M3062AFCTGP-U. This 16-bit M16C/60 core microcontroller operates at 24MHz and features 128KB of FLASH program memory. It includes 10KB of RAM and offers 85 I/O pins. Integrated peripherals include DMA and WDT. The device supports I2C, IEBus, and UART/USART communication protocols. Analog capabilities are provided by 26x10-bit A/D converters and 2x8-bit D/A converters. Supplied in a 100-LFQFP (14x14) surface mount package, this component operates within a temperature range of -40°C to 85°C and requires a supply voltage of 2.7V to 5.5V. This component finds application in automotive, industrial, and consumer electronics sectors.
Additional Information
Series: M16C™ M16C/60/62PTRoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 100-LQFP |
| Mounting Type | Surface Mount |
| Speed | 24MHz |
| Program Memory Size | 128KB (128K x 8) |
| RAM Size | 10K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | M16C/60 |
| Data Converters | A/D 26x10b; D/A 2x8b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | I2C, IEBus, UART/USART |
| Peripherals | DMA, WDT |
| Supplier Device Package | 100-LFQFP (14x14) |
| Number of I/O | 85 |
| Programmable | Not Verified |
