M30620FCMFP#D3
IC MCU 16BIT 128KB FLASH 100QFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
The Renesas Electronics Corporation M16C™ M16C/62M series microcontroller, part number M30620FCMFP-D3, features a 16-bit M16C/60 core processor operating at 10MHz. This device offers 128KB of FLASH program memory and 10KB of RAM. Integrated peripherals include DMA and WDT, alongside PWM capabilities for precise control. The microcontroller supports serial communication via SIO and UART/USART interfaces. Analog functionality is provided by 10x10-bit A/D converters and 2x8-bit D/A converters. Housed in a 100-QFP (14x20) surface-mount package, this component is suitable for applications requiring robust processing and connectivity. It operates within a voltage range of 2.2V to 3.6V and an ambient temperature range of -40°C to 85°C. This component finds application in industrial automation and consumer electronics.
Additional Information
Series: M16C™ M16C/62MRoHS Status: Not applicableManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 100-BQFP |
| Mounting Type | Surface Mount |
| Speed | 10MHz |
| Program Memory Size | 128KB (128K x 8) |
| RAM Size | 10K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | M16C/60 |
| Data Converters | A/D 10x10b; D/A 2x8b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.2V ~ 3.6V |
| Connectivity | SIO, UART/USART |
| Peripherals | DMA, PWM, WDT |
| Supplier Device Package | 100-QFP (14x20) |
| Number of I/O | 85 |
| Programmable | Not Verified |
