M30280FATHP#U3
MCU LQFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation M16C/60 microcontroller, part number M30280FATHP-U3, offers a 16-bit M16C/60 core operating at 20MHz. This device features 96KB of FLASH program memory and 8KB of RAM, complemented by 4KB of EEPROM. Integrated peripherals include DMA, POR, PWM, Voltage Detect, and WDT. Connectivity options are available via I2C, IEBus, SIO, and UART/USART interfaces. The M16C™ M16C/Tiny/28 series component is packaged in an 80-LQFP (12x12) surface mount configuration. It includes 24x10-bit Analog-to-Digital converters and provides 71 I/O lines. Designed for operation across a -40°C to 85°C temperature range, this microcontroller is suitable for applications in automotive, industrial automation, and consumer electronics. The internal oscillator simplifies design, and the supply voltage range is 2.7V to 5.5V.
Additional Information
Series: M16C™ M16C/Tiny/28RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 80-LQFP |
| Mounting Type | Surface Mount |
| Speed | 20MHz |
| Program Memory Size | 96KB (96K x 8) |
| RAM Size | 8K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 4K x 8 |
| Core Processor | M16C/60 |
| Data Converters | A/D 24x10b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | I2C, IEBus, SIO, UART/USART |
| Peripherals | DMA, POR, PWM, Voltage Detect, WDT |
| Supplier Device Package | 80-LQFP (12x12) |
| Number of I/O | 71 |
| Programmable | Not Verified |
