HD64F3670FY
IC MCU 16BIT 8KB FLASH 48LQFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation HD64F3670FY is a 16-bit H8/300H Tiny microcontroller featuring an H8/300H core. This device operates at 16MHz and is equipped with 8KB of FLASH program memory and 2KB of RAM. On-chip peripherals include PWM and WDT, along with an SCI interface for connectivity. It also incorporates 4x10-bit A/D data converters. The HD64F3670FY offers 26 general-purpose I/O pins and supports surface mount installation via its 48-LQFP (7x7) package. Operating voltage ranges from 3V to 5.5V, with an operational temperature range of -20°C to 75°C. This component is suitable for applications in industrial automation and consumer electronics.
Additional Information
Series: H8® H8/300H TinyRoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 48-LQFP |
| Mounting Type | Surface Mount |
| Speed | 16MHz |
| Program Memory Size | 8KB (8K x 8) |
| RAM Size | 2K x 8 |
| Operating Temperature | -20°C ~ 75°C |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | H8/300H |
| Data Converters | A/D 4x10b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V |
| Connectivity | SCI |
| Peripherals | PWM, WDT |
| Supplier Device Package | 48-LFQFP (7x7) |
| Number of I/O | 26 |
| Programmable | Not Verified |
