HD6417616SFV
IC MCU 32BIT ROMLESS 208LQFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation SuperH® SH Ethernet microcontroller, part number HD6417616SFV, is a 32-bit single-core SH-2 DSP processor operating at 62.5MHz. This ROMless microcontroller features 8K x 8 RAM and is housed in a 208-LQFP (28x28) surface mount package. Connectivity options include EBI/EMI, Ethernet, IrDA, FIFO, SCI, and SIO. Integrated peripherals include DMA, POR, PWM, and WDT. This component is suitable for applications requiring high-performance processing and robust connectivity, often found in industrial automation, networking equipment, and automotive systems. The operating temperature range is -20°C to 75°C.
Additional Information
Series: SuperH® SH EthernetRoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 208-LQFP |
| Mounting Type | Surface Mount |
| Speed | 62.5MHz |
| Program Memory Size | - |
| RAM Size | 8K x 8 |
| Operating Temperature | -20°C ~ 75°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | ROMless |
| EEPROM Size | - |
| Core Processor | SH-2 DSP |
| Data Converters | - |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | EBI/EMI, Ethernet, IrDA, FIFO, SCI, SIO |
| Peripherals | DMA, POR, PWM, WDT |
| Supplier Device Package | 208-LQFP (28x28) |
| Number of I/O | 29 |
| Programmable | Not Verified |
