DF2145BFA20IV
IC MCU 16BIT 256KB FLASH 100QFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
H8S/2000 H8® H8S/2100 Microcontroller IC 16-Bit 20MHz 256KB (256K x 8) FLASH 100-QFP (14x14)
Additional Information
Series: H8® H8S/2100RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 100-BFQFP |
| Mounting Type | Surface Mount |
| Speed | 20MHz |
| Program Memory Size | 256KB (256K x 8) |
| RAM Size | 8K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | H8S/2000 |
| Data Converters | A/D 8x10b; D/A 2x8b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
| Connectivity | I2C, IrDA, SCI, X-Bus |
| Peripherals | PWM, WDT |
| Supplier Device Package | 100-QFP (14x14) |
| Number of I/O | 74 |
| Programmable | Not Verified |
Request a Quote
