D13002X16V
IC MCU 16BIT ROMLESS 100QFPManufacturer: Renesas Electronics Corporation
Categories: Microcontrollers
Quality Control: Learn More
Renesas Electronics Corporation H8® H8/300H series microcontroller, part number D13002X16V, is a 16-bit ROMless MCU featuring an H8/300H core operating at 16MHz. This component offers 512 x 8 bytes of RAM and 38 I/O lines. Integrated peripherals include DMA, PWM, and WDT, along with an 8-channel, 10-bit A/D converter. Connectivity is supported via SCI. The device operates within a voltage range of 2.7V to 5.5V and is specified for an operating temperature range of -20°C to 75°C. It is supplied in a 100-QFP (14x14) package suitable for surface mounting. This microcontroller is commonly utilized in industrial automation, consumer electronics, and automotive applications.
Additional Information
Series: H8® H8/300HRoHS Status: Not applicableManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 100-BFQFP |
| Mounting Type | Surface Mount |
| Speed | 16MHz |
| Program Memory Size | - |
| RAM Size | 512 x 8 |
| Operating Temperature | -20°C ~ 75°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | ROMless |
| EEPROM Size | - |
| Core Processor | H8/300H |
| Data Converters | A/D 8x10b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | SCI |
| Peripherals | DMA, PWM, WDT |
| Supplier Device Package | 100-QFP (14x14) |
| Number of I/O | 38 |
| Programmable | Not Verified |
