AT45DB021E-SHN2B-T
IC FLASH 2MBIT SPI 70MHZ 8SOICManufacturer: Renesas Electronics Corporation
Categories: Memory
Quality Control: Learn More
The Renesas Electronics Corporation AT45DB021E-SHN2B-T is a 2Mbit non-volatile FLASH memory component. It features a serial peripheral interface (SPI) with a maximum clock frequency of 70 MHz, enabling efficient data transfer. The memory is organized into 1024 pages, each with 256 bytes, and supports byte-level page write operations with a write cycle time of 8µs and a page write time of 3ms. This component operates within a supply voltage range of 1.65V to 3.6V and is rated for an operating temperature of -40°C to 85°C. The AT45DB021E-SHN2B-T is housed in an 8-SOIC package, suitable for surface mounting. Its high-speed SPI interface and reliable FLASH technology make it suitable for applications in industrial control, consumer electronics, and automotive systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.209"", 5.30mm Width) |
| Mounting Type | Surface Mount |
| Memory Size | 2Mbit |
| Memory Type | Non-Volatile |
| Operating Temperature | -40°C ~ 85°C (TC) |
| Voltage - Supply | 1.65V ~ 3.6V |
| Technology | FLASH |
| Clock Frequency | 70 MHz |
| Memory Format | FLASH |
| Supplier Device Package | 8-SOIC |
| Write Cycle Time - Word, Page | 8µs, 3ms |
| Memory Interface | SPI |
| Memory Organization | 256 Bytes x 1024 pages |
| Programmable | Verified |
