AT45DB011D-SH-T-AD
IC FLASH 1MBIT SPI 66MHZ 8SOICManufacturer: Renesas Electronics Corporation
Categories: Memory
Quality Control: Learn More
The Renesas Electronics Corporation AT45DB011D-SH-T-AD is a 1Mbit non-volatile FLASH memory component featuring an SPI interface. This device operates at a maximum clock frequency of 66 MHz and supports a voltage range of 2.7V to 3.6V. The memory is organized into 512 pages, with each page containing 264 bytes. It utilizes a surface mount technology and is housed in an 8-SOIC package with a standard width of 0.209 inches (5.30mm). The component is designed for operation within an industrial temperature range of -40°C to 85°C. Write cycle time for a word or page is 4ms. This memory solution is suitable for applications in industrial automation, consumer electronics, and communication systems requiring reliable data storage. The part is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: 6 week(s)Product Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.209"", 5.30mm Width) |
| Mounting Type | Surface Mount |
| Memory Size | 1Mbit |
| Memory Type | Non-Volatile |
| Operating Temperature | -40°C ~ 85°C (TC) |
| Voltage - Supply | 2.7V ~ 3.6V |
| Technology | FLASH |
| Clock Frequency | 66 MHz |
| Memory Format | FLASH |
| Supplier Device Package | 8-SOIC |
| Write Cycle Time - Word, Page | 4ms |
| Memory Interface | SPI |
| Memory Organization | 264 Bytes x 512 pages |
| Programmable | Not Verified |
