7134LA35CB
IC SRAM 32KBIT PARALLEL SB48Manufacturer: Renesas Electronics Corporation
Categories: Memory
Quality Control: Learn More
Renesas Electronics Corporation offers the 7134LA35CB, a 32Kbit parallel asynchronous SRAM with dual-port functionality. This component features a 4K x 8 memory organization and a fast access time of 35 ns. Designed for robust operation, it supports a supply voltage range of 4.5V to 5.5V and operates across an extended temperature range of -55°C to 125°C. The device is housed in a 48-SIDE BRAZED package, suitable for through-hole mounting. Its asynchronous, dual-port architecture makes it ideal for applications requiring high-speed data buffering and independent read/write operations, commonly found in industrial control systems and high-performance computing. The write cycle time is also rated at 35 ns.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 48-DIP (0.600"", 15.24mm) |
| Mounting Type | Through Hole |
| Memory Size | 32Kbit |
| Memory Type | Volatile |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Voltage - Supply | 4.5V ~ 5.5V |
| Technology | SRAM - Dual Port, Asynchronous |
| Memory Format | SRAM |
| Supplier Device Package | 48-SIDE BRAZED |
| Write Cycle Time - Word, Page | 35ns |
| Memory Interface | Parallel |
| Access Time | 35 ns |
| Memory Organization | 4K x 8 |
| Programmable | Not Verified |
