ISL9307IRTAANGZ-T7A
IC REG QUAD BUCK/LNR SYNC 16TQFNManufacturer: Renesas Electronics Corporation
Categories: Linear + Switching
Quality Control: Learn More
Renesas Electronics Corporation's ISL9307IRTAANGZ-T7A is a highly integrated power management IC featuring four independent voltage regulators. This component offers a combination of two 3MHz synchronous buck converters, each capable of delivering up to 1.5A, and two linear (LDO) regulators with a 300mA output capability. The device supports an input voltage range of 1.5V to 5.5V. Its configurable outputs allow for precise voltage regulation, with the buck converters supporting outputs from 0.8V to 5.5V and the LDOs typically configured for fixed outputs such as 3.3V. Packaged in a compact 16-TQFN (4x4) with an exposed pad for enhanced thermal performance, this solution is designed for surface mount applications. The ISL9307IRTAANGZ-T7A is suitable for power-sensitive applications across various industries, including consumer electronics and mobile devices, requiring efficient and flexible power delivery. It operates within an ambient temperature range of -40°C to 85°C and is supplied on tape and reel.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-WQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 1.5V ~ 5.5V |
| Frequency - Switching | 3MHz |
| Topology | Step-Down (Buck) Synchronous (2), Linear (LDO) (2) |
| Supplier Device Package | 16-TQFN (4x4) |
| Voltage/Current - Output 1 | 0.8V ~ 5.5V, 1.5A |
| Voltage/Current - Output 2 | 0.8V ~ 5.5V, 1.5A |
| Voltage/Current - Output 3 | 3.3V, 300mA |
| w/LED Driver | No |
| w/Supervisor | No |
| w/Sequencer | No |
| Number of Outputs | 4 |
