ISL9305IRTBCNLZ-T
IC REG QUAD BUCK/LNR 3MHZ 16TQFNManufacturer: Renesas Electronics Corporation
Categories: Linear + Switching
Quality Control: Learn More
Renesas Electronics Corporation ISL9305IRTBCNLZ-T is a versatile power management IC featuring four independent voltage regulators. This component integrates two step-down (buck) converters and two linear (LDO) regulators, offering a flexible power solution. The buck converters operate at a 3MHz switching frequency, supporting efficient voltage conversion. The device is housed in a compact 16-TQFN (4x4) package with an exposed pad for enhanced thermal performance, suitable for surface mount applications. The ISL9305IRTBCNLZ-T supports an input voltage range from 1.5V to 5.5V. Specific output configurations include 1.5V at 800mA and 1.8V at 800mA for the buck outputs, and 3.3V at 350mA for one of the linear outputs. This component is commonly utilized in battery-powered devices, consumer electronics, and mobile applications where efficient and compact power delivery is critical. It is supplied on a tape and reel for automated assembly.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-WQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 1.5V ~ 5.5V |
| Frequency - Switching | 3MHz |
| Topology | Step-Down (Buck) (2), Linear (LDO) (2) |
| Supplier Device Package | 16-TQFN (4x4) |
| Voltage/Current - Output 1 | 1.5V, 800mA |
| Voltage/Current - Output 2 | 1.8V, 800mA |
| Voltage/Current - Output 3 | 3.3V, 350mA |
| w/LED Driver | No |
| w/Supervisor | No |
| w/Sequencer | No |
| Number of Outputs | 4 |
