ISL80121IR50Z-T7A
IC REG LINEAR 5V 1A 10DFNManufacturer: Renesas Electronics Corporation
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Renesas Electronics Corporation's ISL80121IR50Z-T7A is a 1A positive fixed output linear voltage regulator. This component features a 5V output and a low dropout voltage of 0.13V at 1A, enabling efficient operation even under heavy loads. The device includes current limit, enable, power good, and soft start control features, along with over-temperature protection. With a quiescent current of 5mA and a maximum input voltage of 6V, it is suitable for applications demanding stable power delivery. The ISL80121IR50Z-T7A is provided in a 10-DFN (3x3) package and is supplied on tape and reel. This regulator is utilized in industrial, medical, and consumer electronics sectors requiring reliable voltage regulation.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 10-VFDFN Exposed Pad |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 1A |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 5 mA |
| Voltage - Input (Max) | 6V |
| Number of Regulators | 1 |
| Supplier Device Package | 10-DFN (3x3) |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 5V |
| Control Features | Current Limit, Enable, Power Good, Soft Start |
| PSRR | 40dB (1kHz) |
| Voltage Dropout (Max) | 0.13V @ 1A |
| Protection Features | Over Temperature |
| Current - Supply (Max) | 7 mA |
